Description
- Type: Digital Mixer
- Channels: 120
- Inputs – Mic Preamps: 32 x XLR
- Phantom Power: 32 Channels
- Outputs – Main: 16 x XLR (main)
- Inputs – Digital: 2 x XLR (AES/EBU), 2 x RJ-45 (Dante)
- Outputs – Digital: 2 x XLR (AES/EBU)
- Busses/Groups: 48 mixes, 12 matrixes, 2 stereo buses, and 2 cue mixes
- MIDI I/O: 1 x 15-pin DIN (GPI)
- Data I/O: 2 x Locking Ethernet (Dante network), 1 x RJ-45 (control)
- Headphones :1 x 1/4″
- USB: 1 x Type C
- Computer Connectivity: USB (18 x 18), Ethernet
- I/O Expansion Slots: 1 x Slots Available
- Word Clock: 2 x BNC (in/out)
- Faders: 28 x Motorized
- A/D Resolution: Up to 24-bit/96kHz
- Effects: Yes
- Signal Processing: 64 Assignable Processing Slots, 16 Assignable FX Slots, 4 x Inserts per Channel
- Features: A.I. Mix Assistant
- Transport Controls: Yes
- DAW Control: Yes
- Screen: 2 x 12″ touchscreen, 7″ touchscreen
- Software: DM7 Editor, DM7 StageMix, Console File Converter, MonitorMix, ProVisionaire Control/Touch
- Power Source: 2 x Standard IEC AC Cable (redundant power supply)
- Height: 12.75″
- Depth: 22.2″
- Width: 31.2″
- Weight: 50.7 lbs.
- Manufacturer Part Number: DM7
